Specifications
Highlights:
| Punch Rating (tons) | 55 |
| Punch Max Capacity (in.) | 1-1/16 diam. in 5/8 mild steel |
| Flat Bar Shear Max Capacity (in.) | 3/8 x 14 1/2 x 12 3/4 x 4 |
| Angle Shear Max Capacity (in.) | 3 x 3 x 3/8 4 x 4 x 1/4 |
| Optional Coper Notcher Max Capacity (in.) | 2-1/2 x 4 x 5/16 |
| Four Workstations | Standard Non-Removable (3): Punch, Flat Bar Shear & Angle Shear Open (1): Right Side (Empty) |
Full Specs:
| Punch Rating (tons) | 55 |
| Punch Max Capacity (in.) | 1-1/16 diam. in 5/8 mild steel |
| Punch Work Height (in.) | 36-9/16 |
| Punch Throat Depth (in.) | 7-1/2 |
| Punch Stroke (in.) | 1-1/4 |
| Flat Bar Shear Max Capacity (in.) | 3/8 x 14 1/2 x 12 3/4 x 4 |
| Flat Bar Shear Work Height (in.) | 34-1/2 |
| Flat Bar Shear Max Round Capacity (in.) | 7/8 diam. |
| Flat Bar Shear Max Square Capacity (in.) | 7/8 |
| Angle Shear Max Capacity (in.) | 3 x 3 x 3/8 4 x 4 x 1/4 |
| Angle Shear Work Height (in.) | 39-7/8 |
| Open Workstation Work Height (in.) | 34-1/2 |
| Open Workstation Throat Depth (in.) | 11-3/16 |
| Optional Coper Notcher Max Capacity (in.) | 2-1/2 x 4 x 5/16 |
| Optional Coper Notcher Work Height (in.) | 39-1/2 |
| Motor | 5 HP |
| Amps | 23 |
| Hydraulics (GPM) | 3-1/2 |
| Hydraulics (PSI) | 2500 |
| Hydraulic Tank (Liters) | 26 |
